Wearable and Implantable Animals Thermometer with Temp View App

Summary

Rectal thermometer SV 224 was coated with lubricating oil and then inserted into the anus of the animal. Use medical tape twine the main unit of thermometer on the tail of animal and read real time data by mobile phone APP.

. It is miniaturized, sealed and waterproof, and weighs 1.4g. The external soft thermal probe is inserted into the anus of the human body to continuously measure and record the body nuclear temperature, which is used for dynamic measurement of body temperature when worn in the anus of the mouse or animals.

Features

·Measurement range: 25.0 ℃ ~ 43.0 ℃, ± 0.2 ℃

·Measurement: 10 seconds / 20 days of measurement data storage

·Record data can be sent to the specified network address

·Transmission distance: external ≥ 10m, internal ≤ 3M

·Smartphone monitors the measurement data of multiple thermometers

·Cell time: 100 days / using life: 45 days

·Product size: D8.9xL22mm/weight: 1.4g

·Soft thermal head size: D1x 95mm

Operating instructions

- tips!!!

The anal warming patch is only used for 45 days. Use it as soon as possible after purchase to avoid expiration.

- Download App TempView: Scan the QR code or download our app TempView in Apple store and Google play.

- Activate the thermometer

Anal warming patch needs to be activated before it can be used. Please activate it according to the following steps:

① Put the thermometer into the freezer of the refrigerator for about 10 minutes, and the temperature of the freezer is required to be ≤ 0 ℃.

② Take out the thermometer from the refrigerator, quickly put the sensing probe into the thermos cup, and keep the hot water in the cup between 40 ℃ and 60 ℃.

③ Fifteen minutes later, take out the thermometer. When the App can scan the device, it indicates that it is activated. Otherwise, repeat the above steps.

—Installation method

Apply lubricating grease to the sensing probe, slowly rotate it or pump it up and down into the anus to a depth of 5cm, and then fix the thermometer at outside of anal by using Band-aid.

—Download record data

①     When downloading records, the mobile phone must be close to the anal temperature patch, and the distance between them should be within 1M.

 Frequently asked questions

Q1 how to increase wireless transmission distance

It is recommended to use a well-known brand of business mobile phone to run the app application TempView.

Q2 Anal warming patch cannot be activated

Check whether the temperature in the refrigerator is lower than 0 ℃, and the water temperature in the thermos cup should be higher than 40 ℃ and lower than 60 ℃.

 Q3 The device cannot be connected

Check whether Bluetooth is enabled on the mobile phone, put the mobile phone within 1 meter of the anal temperature sticker or restart the app, and repeat the operation many times.

Q4 Records cannot be downloaded

In the process of downloading the recorded data, the following contents are always displayed on the screen for 2 minutes. Please put the mobile phone close to the thermometer and run the operation again.

Q5 How to increase the service life

When the thermometer is not in use, put it in the refrigerator below zero degrees and reactivate it when in use.
